CHT-PLA3777A Cissoid 1200V/20A Buck or Boost SiC MOSFET module

Manufacturer: CISSOID
Model:CHT-PLA3777A
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Stock Condition:New original, 158 pcs Stock Available.
Ship From:Shen Zhen / Hong Kong
Shipment Way:DHL/Fedex/TNT/UPS
Contact:[email protected]
WhatsApp:+86 13410359515

Datasheet

Part Number	CHT-PLA3777A
Manufacturer / Brand	Cissoid
Stock Quantity	158pcs Stock
Description	Transistors & Diodes > CHT Series (-55°C to 225°C):SiC power devices
Lead Free Status / RoHS Status:	Lead free / RoHS Compliant
Condition	New Original Stock
Warranty	100% Perfect Functions
Lead Time	2-3days after payment.
Payment	PayPal / Telegraphic Transfer / Western Union
Shipping by	DHL / Fedex / UPS/TNT
Port	HongKong
RFQ Email	[email protected]

The CHT-PLA3777A is a high-temperature 1200V/20A Buck or Boost Module, i.e. a module including one Silicon Carbide (SiC) MOSFET and one SiC Schottky Diode, independent from each other. It is suitable to implement high-efficiency Buck (step-down) or Boost (step-up) DC-DC converters in high temperature environments. This product is guaranteed for normal operation on the full range -55°C to +210°C (Tj). Each device has a breakdown voltage in excess of 1200V and is capable of switching current up to 20A. The SiC MOSFET has an On-resistance of 60mΩ at 25°C and 120mΩ at 210°C at VGS=20V. The SiC Schottky Diode has a forward voltage of 1.5V at 20A.
